TYM T273 HST User Manual

SECTION 5. EARTHING POINT
Fig.10-24
1) Front axle bracket (RH)
Earthed at upper tapped hole in the axle bracket.
3)
Earthed at upper tapped hole in the dash panel.
1)Front axle bracket
3) In the dash cover
10-11
3)
Earthed at upper tapped hole in the dash panel.
Fig.10-25
Fig.10-26
2) Contact surfaces of the axle bracket and engine
where they tightened together
