TYM T353HST - Page 128

(4) Rear PTO mechanism
Shift stay
PTO shaft
Counter shaft
1.Gear,spur12
2.R.B.B(6305)
3.C-ring,shaft
4.R.B.B(6205)
5.Gear spur,14
6.C
-
ring,shaft
Fig.5-45
6.C
-
ring,shaft
7.C-ring,hole
8.Seal 62
9.Shaft,PTO
10.C-ring,shaft
11.R.B.B(6205)
12.Gear,spur 37
13.Collar(35X50X2)
14.R.B.B(6207)
15.C-ring(hole)
16.Oil seal
17.Cover
18.Bolt
19.Hook,rear PTO
20.Lever,rear PTO
21.Stay,PTO shift
22.Shifter,PTO Low
speed
5-27
Fig.5-46
Fig.5-47
