TYM T454HST - Universal Symbols

2 - 6
UNIVERSAL SYMBOL
UNIVERSAL SYMBOLS
Some of the universal symbols have been shown below with an indication of their meaning
Engine speed
( rev/minX100)
Pressured-open
slowly
Corrosive
substance
Hours, recorded
Continuous
variable
”Tortoise” Slow or
minimum Setting
Engine
coolant
temperature
Warning
Hare” fast or
maximum setting
Fuel level Hazard warning
Transmission oil
pressure
Engine
Stop
control
Neutral Turn signal
Lights Fan
Transmission oil
temperature
