3 - 19
Tractor will be difcult to
turn if the Diff-lock is en-
gaged, ensure the lock is
disengaged before turning
the steering wheel.
Danger
Do not use high engine
RPM when engaging Diff
lock If the diff lock does
not release after removing
the foot from the diff lock
pedal alternatively brake
with the left and right brake
until it gets released.
Important
Never use the diff lock at
high speed or on the road as
this can cause roll over and
injury.
Caution
► FRONT WHEEL DRIVE LEVER
(4WD)
In the ON position the front wheels are en-
gaged and in the OFF position they are disen-
gaged.
Engage & disengage the front wheel drive with
the front wheels in the straight position and at
low Engine RPM.
Do not use front wheel
drive at high speed or on
the road as premature wear
of components will result.
Important
Use of front wheel drive improves traction
performance.
