4 - 5
SECTION B
4
► INSTALLING LOADER
1.Connect P port of loader control valve to the line on the tractor marked P(from the PTO valve)
2.Connect the T port on the loader control valve to the line on the tractor marked T
3.Connect the remaining line from the control valve to the line on the tractor marked P1 ( to the transmission housing)
► DETACHING THE LOADER (LOADER CONNECTING PORT)
1.Detach the hydraulic hoses of loader
2.Assemble the cap (PF3/8) with pipe comp (PF3/8).
LOADER Valve
Transmission oil Filter
