TYM T454HST - Page 86

4 - 10
SECTION B
No. Filling point Fillings Quantity Liter (gal.)
MODEL
T454HST / T554HST
1
RADIATOR
50/50 : Ethylene Glycol/Water (L.L.C)
ASTM D4985 / D6210
9.3ℓ(2.5US gal)
2
ENGINE
API : (CJ-4 Grades (API ACEA E-6, JASO PH-2, Grade 10W30
Recommended SAE viscosity grades
A: Viscosity / B: Temperature
5.3ℓ(1.4US gal)
3
TRANSMISSION CASE
API GL-4 Grade
Tractor transmission and hydraulic oil
Below -4ºF(-20ºC) ISO VG32
Above -4ºF(-20ºC) between ISO VG46 and 68
35ℓ(9.24 US gal)
4
FRONT AXLE
API GL-4 Grades(SAE 80W/90 )
10ℓ(2.64 US gal)
5
FINAL DRIVE CASE(B)
API GL-4 Grades(SAE 80W/90 )
6
BALL JOINT
Grease
As required
7
FUEL TANK
Diesel fuel
60ℓ(15.85 US gal)
► RECOMMENDED TRANSMISSION OIL
①
RPM Tractor Hydraulic Fluid or Textron TDH Premium (CALTEX)
②
TDH Oil or TDH Oil special (TEXACO)
③
Chevron 1000THF (CHEVRON)
