►WARNING LIGHTS
Charge lamp
This light will go off as soon as the engine starts to run to indicate that the
alternator is changing. (Please note, as broken fan belt can cause the light to come
on, please stop the engine as overheating can occur if not rectified immediately)
Oil pressure lamp
Will go out as soon as the engine starts if the oil pressure is correct. If it
comes on while the engine is running, stop the engine and get expert
advice.
36
PTO monitor Lamp
Shows the revolution of PTO
Refer to monitor lamp on Page 36
High beam lamp is operated on the combination switch.
Low beam lamp is operated on the combination switch
Glow signal Lamp indicates preheating
Parking brake is operated when footbrake is engaged.
Fuel Level : If it comes on while the engine is running, Fill the tank with fuel.
Transmission oil filter lamp comes On when Gearbox oil filter clogged,
and/or Low gearbox oil pressure
Over-run of front wheel drive
Water separator lamp
