2008 5 600OPTRS
MODEL 600
QUICK REFERENCE SERVICE CHART
(M00588)
ITEM DESCRIPTION RECOMMENDED SERVICE
1. Truck Engine Check oil level DAILY! Change oil and oil filter every
100 hours or every 3000 miles.
2. Truck Air Cleaner Inspect restriction indicator DAILY!
3. Dual Steering Gear Box Inspect monthly. Install grease as required.
4. Water Tank Drain tank DAILY!
5. Auxiliary Engine Change oil and oil filter every 100 hours. Check oil
level DAILY!
6. Auxiliary Engine Air Cleaner Inspect restriction indicator DAILY!
7. Hydraulic Oil Filter Change every 100 hours.
8. Hydraulic Oil Check DAILY. Change out after initial 100 hours; then
every 1000 hours (21.5 gal. reservoir) Use 10W motor oil.
9. Separator Inlet Scroll Remove hopper screen and clean inlet every 500 hours.
10. Blower Power Band Re-tension after initial 10 hours; then every 500 hours.
11. Separator Door Open and wash out separator chamber DAILY!
12. Hopper Screen Thoroughly wash screen DAILY; Never use sweeper
with large tears in screen.
13. Separator Door Opener Wash sheave and cable DAILY!
14. Suction/Pressure/ Hand Hoses Check DAILY for holes and wear.
15. Sweeper Door Seals Inspect door seals DAILY; Hopper must be airtight.
Replace leaking or damaged seals.
16. Electric Water Pump Protect from freezing. No daily service necessary.
17. Truck Differential Follow manufacturers recommended service program.
18. Truck Tires Inspect each tire DAILY for flats and correct air pressure.
19. Turning Vanes/Pick-Up Head Inspect DAILY! Remove any material collected on
vanes. Replace as needed.
20. Pick-Up Head Curtains Inspect DAILY! Replace as required.
21. Gutter Broom Check DAILY for string, wire, cassette tape etc. on motor
shaft.
22. Truck Chassis Grease every 100 hours or 3000 miles.
* CNG Filters (Optional) Check Weekly.
NEVER REACH INTO BLOWER HOUSING FOR ANY REASON !
