7
Plug the Mini USB
power cable into
the DC input port.
Attach the
Windshield Mount
onto the Dash Cam
and slide to the left.
4
5
Adjust the Windshield
Mount to get the best
angle.
Warning: Do not install the product in a location where it can obstruct the driver’s
eld of vision.
Check the live screen in TYPE S Drive APP and determine the most suitable mounting
position. (See page 17 on using the APP.)
6
Recommended mounting position
