3. RJ-11 Pin Assignment
Pin
Signal
Signal
Direction
Description
1
Ground
---
Frame Ground
2
Cash Drawer
Kick Out Signal
1
Output
3
Cash Drawer
Status
Input
Open/Close
4
+VDC 24v
---
5
Cash Drawer
Kick Out Signal
2
Output
6
GND
---
Signal Ground
