u-blox LEA-5 Series - Page 33

LEA-5, NEO-5, TIM-5H - Hardware Integration Manual
GPS.G5-MS5-09027-A2 Released Design-in
Page 33 of 68
17.0 mm [669 mil]
22.4 mm [881.9 mil]
1.0 mm
[39 mil]
0.8 mm
[31.5 mil]
2.45 mm [96.5 mil]
1.1 mm
[43 mil]
3.0 mm
[118 mil]
2.15 mm
[84.5 mil]
0.8 mm
[31.5 mil]
Figure 18: LEA-5 footprint
Stencil: 200 m
15.7 mm [618 mil]
17.0 mm [669 mil]
20.8 mm [819 mil]
0.8 mm
[31.5 mil]
0.6 mm
[23.5 mil]
Figure 19: LEA-5 paste mask
12.2 mm [480.3 mil]
16.0 mm [630 mil]
1.0 mm
[39.3 mil]
0.8 mm
[31.5 mil]
0.8 mm
[31.5 mil]
3.0 mm
[118.1 mil]
1.0 mm
[39.3 mil]
1.1 mm
[43.3 mil]
Figure 20: NEO-5 footprint
Stencil: 170 m
10.4 mm [409.5 mil]
14.6 mm [575 mil]
12.2 mm [480 mil]
0.8 mm
[31.5 mil]
0.6 mm
[23.5 mil]
Figure 21: NEO-5 paste mask
