MAX-7 / NEO-7 / LEA-7 - Hardware Integration Manual
GPS.G7-HW-11006-1 Preface
Page 3 of 55
Preface
u-blox Technical Documentation
As part of our commitment to customer support, u-blox maintains an extensive volume of technical
documentation for our products. In addition to our product-specific technical data sheets, the following manuals
are available to assist u-blox customers in product design and development.
• GPS Compendium: This document, also known as the GPS book, provides a wealth of information
regarding generic questions about GPS system functionalities and technology.
• Receiver Description including Protocol Specification: Messages, configuration and functionalities of
the u-blox 7 software releases and positioning modules are explained in this document.
• Hardware Integration Manual: This Manual provides hardware design instructions and information on
how to set up production and final product tests.
• Application Note: document provides general design instructions and information that applies to all u-blox
GPS/GNSS positioning modules. See section Related documents for a list of Application Notes related to your
GPS/GNSS receiver.
How to use this Manual
The MAX-7, NEO-7 and LEA-7 Hardware Integration Manual provides the necessary information to successfully
design in and configure these u-blox 7-based positioning modules. For navigating this document, please note
the following:
This manual has a modular structure. It is not necessary to read it from the beginning to the end. To help in
finding needed information, a brief section overview is provided below
1. Hardware description: This chapter introduces the basics of function and architecture of the u-blox 7
modules.
2. Design: This chapter provides the information necessary for a successful design.
3. Product handling: This chapter defines packaging, handling, shipment, storage and soldering.
4. Product testing: This chapter provides information about testing of OEM positioning modules in
production.
5. Migration to u-blox-7 modules: includes guidelines on how to successfully migrate to u-blox 7 designs.
The following symbols are used to highlight important information within the manual:
An index finger points out key information pertaining to module integration and performance.
A warning symbol indicates actions that could negatively influence or damage the module.
Questions
If you have any questions about u-blox 7 Hardware Integration, please:
• Read this manual carefully.
• Contact our information service on the homepage
http://www.u-blox.com
• Read the questions and answers on our FAQ database on the homepage
http://www.u-blox.com
