MAX-7 / NEO-7 / LEA-7 - Hardware Integration Manual
GPS.G7-HW-11006-1 Appendix
Page 54 of 55
Revision history
Revision Date Name Status / Comments
- September 4, 2012 jfur Initial draft
1 December 20, 2012 jfur MAX-7W added, Revision Chapter 3.4 Antenna supervision
DC-bloc removed from Figure 21 and Figure 22.
MAX-7C: Higher backup current, new Figure 42 and 43
