4-49
Section 4 - Parts
Item Part No. Description
80-39010-00 Ice Maker Assembly
150-CO2175F Faceplate Assembly
1 627000 Cover
2 628210*† Gear
3 80-39015-00* Motor
4 627163*† Spring
5 625836*† Valve switch plate
6 31403* Switch spacer
7 627302*† Cam
8 627680* Insulator
9 2506* Hold switch
10 2918 Wire harness
11 2506* Valve switch
12 625827 Support housing
13 2886 Bin arm
14 627526 Spring, bin arm
15 627375 Ejector
16 625843-S Mold heater
17 31400 Stripper
18 489128 Screw, stripper
19 628123-S-E75 Mold and Heater Assembly
20 544304 Water cup
21 488372*† Screw, spring and housing
22 488957*† Screw, gear
23 11641*† Faceplate
24 41375 Screw, plate
25 488361* Screw, long sw
26 488362* Screw, short sw
27 488360 Screw, bin sw
28 625829 Clamp
29 625830 Arm lever
30 627199 Screw, arm lever
31 488622* Screw, motor
32 2506* Bin switch
33 42166 Support bracket
34 2917 Limit Switch
Not 68092 Thermistor
Shown
* included with 150-CO2175 faceplate assembly
† included with 80-39015-00 motor
CO2175F (4 of 4)
