4-31
Section 4 - Parts
item Part No. Black Part No. White Part No. Description
Stainless Steel
1 11964-01 11964-01 11964-01 Back panel
2 80-17073-01 80-17073-02 80-17073-03 Door Assembly, RH Hinge
N/A N/A 80-17073-13 Door Assembly, LH Hinge
3 80-10050-01-S 80-10050-02-S 80-10050-03-S Evaporator/Cabinet Assembly
4 402-B12015 402-B12015 402-B12015 Ice Maker Assembly
150 150 150 Face Plate Assembly (see page 2-)
5 11898-S-BLK 11898-S-KIT 11995-S-SS Hinge Assembly, top, RH
6 31430 31430 31430 Ice bucket
7 11899-S-BLK 11899-S-KIT 11996-S-SS Hinge Assembly, lower
8 42096 42906 42906 Pivot screw
9 42101-BLK 42101-ZP 42101-SS Screw, hinge
10 80-29012-01 80-29012-02 80-29012-01 Grille Assembly
11 2694 2694 2694 Dryer
12 2303-02-S 2303-02-S 2303-02-S Condenser Assembly
13 5263-S 5263-S 5263-S Fan motor
14 5188 5188 5188 Fan blade
15 2552A 2552A 2552A Water valve
16 2780 2780 2780 Control
17 404-BI2X15 404-BI2X15 404-BI2X15 Fill Tube Assembly
18 41254 41254 41254 Plastic Nut & Sleeve Assembly
19 41319 41319 41319 Leg, leveling
20 5402-S 5402-S 5402-S Compressor
21 5413 5413 5413 Overload
22 5414 5414 5414 Relay
23 26071-01 26071-02 14160-01 Door handle
24 12094-04-S 12094-06-S 12094-05-S Door gasket (includes #33)
25 31673-S 31673-S 31673-S Door Closer Assembly
26 11901-1 11901-1 11994-BLK Pivot plate
27 2905 2905 2905-2 Power cord
28 41826 41826 41826 Brass fitting, 90°
29 2053 2053 2053 On/Off switch
30 42090-BLK 42090-BLK 42090-BLK Knob, control
31 41156-02 41156 41156 Plug, threaded hole
32 42161-ZP 42161-ZP 42161-ZP Screw, pivot plate
33 12095-04 12095-06 12095-05 Gasket, horizontal
34 23025 23025 23025 Nameplate
35 2800 2800 2800 Process tube
Not N/A N/A 14159-01 Commercial Handle (SS accessory only)
Shown
MODEL BI-2115
