4-33
Section 4 - Parts
Item Part No. Black Part No. Description
Stainless Steel
1 11964-01 11964-01 Back Panel
2 402-BI2015 402-BI2015 Ice Maker Assembly
150 150 Face Plate Assembly (see page 2-)
3 31430 31430 Ice Bucket
4 23029 23029 Nameplate
5 31447-BLK 31447-Blk Hole Plug
6 31604-GRY 31604-GRY Door Gasket
7 41604 N/A Handle Screws
8 26077-01 N/A Top Handle Assembly
9 80-17122-01 80-17123-03 Door Assembly Right Hand
N/A 80-17123-13 Door Assembly Left Hand
10 41893-BLK 41893-BLK Hinge Screws
11 41785-SSB 41785-SSB Pivot Screw Top
12 11697-ST-BLK 14126-ST Hinge Assembly Top
13 41747-SSB 41747-SSB Pivot Screw Bottom
14 14312-01 14132-02 Hinge Assembly Bottom
15 5414 5414 Relay
16 5413 5413 Overload
17 5402-S 5402-S Compressor Assembly
18 41319 41319 Leg Levelers
19 74014-S 74014S Compressor Assembly
20 42090-BLK 42090-BLK Control Knob, Black
21 2780 2780 Control
22 404-BI2X15 404-BI2X15 Fill Tube Assembly (includes water line)
23 5188 5188 Fan Blade
24 5263-S 5263-S Fan Motor
25 2905 2905 Power Cord
26 2819 2819 Process Tube
27 2694 2694 Drier
28 41254 41254 Plastic Nut & Sleeve Assembly
29 41826 41826 Brass Fitting
30 2552S 2552A Water Valve
31 80-29019-01 80-29019-01 Grille Assembly
32 2053 2053 On/Off Switch
33 80-10080-01-S 80-10080-01-S Evaporator/Cabinet Assembly
MODEL ADA15IM
