24
User’s Manual
1. Remove the control knob by grasping the knob and pulling straight
off (see Figure 22).
2. Remove the screws at each end of the grille.
3. Remove the grille.
DO NOT touch the condenser fins. The condenser fins are
SHARP and can be easily damaged.
4. Clean the condenser coil using a brush or vacuum cleaner. Do not
touch.
5. Position the grille to align the screw holes with the cabinet.
6. Insert the grille screws and tighten being careful not to overtighten.
7. Install the control knob by aligning the flat of the control knob with
the flat on the shaft. Push firmly.
WINE RACK REMOVAL/INSTALLATION
To remove the wine racks for cleaning:
1. Grasp the end of the wine rack,
sliding it out and up.
2. Clean wine rack with a damp rag.
To insert the wine racks:
1. Position the wine rack above the
shelf channel where the rack is to
be inserted. (See Figure 23.)
2. Slide the rack on the channel at an
angle until the rack is in the chan-
nel.
3. Continue sliding until the rack is all
the way into the Wine Captain
®
.
UL302
Figure 23
30_10008_E_WC_UM.qxd 3/2/05 2:23 PM Page 24
