U-Line Wine Captain User Manual

13
LEVELING THE UNIT
Position the unit on a flat, level surface, capable of supporting the
entire weight of the unit when full.
This unit contains four adjustable leveling legs. Turn the legs
clockwise to raise and counterclockwise to lower (see Figures 3 & 4).
Figure 3 Figure 4
REVERSING THE DOOR
All Wine Captain
®
models (except Stainless Steel models which must be
ordered left or right hand opening) are field reversible for left or right hand
opening. The door opening is easily reversed by moving the hinge hardware
to the opposite side (see Figure 5).
Figure 5
UL318
UL314
CHECK
LEVEL
UL105
TURN FOOT TO ADJUST
30_10008_E_WC_UM.qxd 3/2/05 2:23 PM Page 13
