G
Mattress position
Step 1 Select mattress base, using two adults lower base into position. It will rest on
the upper mattress support brace.
Step 2 Screw in 20mm length bolts to secure base. Please Note: Do not over-tighten.
Step 3 Align mattress base with bolt holes and attach one bolt at each end.
Finger tighten.
Step 4 Install two remaining bolts then tighten all four bolts with Allen Key.
4 x 20mm Bolt
16
