A
Base assembly
Step 1 Clear floor space.
Step 2 Lay Plastic Base upside down on a flat surface.
Step 3 Place foot plate into recess area as shown in diagram.
Step 4 Screw in four 10mm length bolts to secure base. Please Note: Do not over-
tighten.
Step 5 Repeat Steps 3 & 4 at other end.
Step 6 Have two adults turn base onto it’s feet.
8 x 10mm Bolt
8
