38 39
Key Port / Ignition Switch
Battery Level Indicator
Headlight Switch
Drive Mode Switch
Horn
Throttle
Front BrakeRear Brake
Warning Light
12v Power Port
(10A Max)
USB Ports
Battery Charge Port
Console View
Powering the 2×2
The 2×2 is equipped with a three stage key switch.
Due to the electric drive, you will not hear a sound
when the bike is turned on. The battery meter
display will illuminate on the console of the bike
and you are good to go.
Position 1: OFF
Position 2: ACC – the low current accessories are
now active (lights, horn, USB port and 12V outlet).
Position 3: RUN – the bike can now be ridden.
Drive Mode Switch
This switch controls power output of the motors.
Switch Down: Eco – Low Power; helps save
battery charge, speed limited.
Switch Up: Power – Full Power and Speed;
best for steep or dicult terrains.
Headlight Control
This controls the high intensity LED headlight:
Switch Down: O
Switch Up: On
1. OFF 2. ACC 3. RUN
HEADLIGHT
DRIVE MODE
