UCS C-SV 4A - Product Description and Components; Unit Description and Components

Doc. 85588U - Rev. 22/10/2020
USER MANUALUSER MANUAL
ENEN
Drw. 32367/h7/54
5. PRODUCT DESCRIPTION

1 Cable inlet plate
2 Buerbaeries
3 Electronic board
4 Powersupplyconneconterminal
5 Cabinetclosingsystem
6 Earthingconnecon
7 Integratedemergencypushbuon
8 Manualopeningpushbuonpanelfornaturalvenlaon
9 Conneconofemergencypushbuon
10 Manualopeningconneconofnaturalvenlaon

5
1
3
6
4
2
7
8
9
10

