12
TO DOWNLOAD THE INFORMATION
Refer to Setup Mode, 01 Data Transfer
TEXT EDITOR
TO ENTER TEXT IN THE TEXT FIELD
If enabled (refer to SET UP MODE 07), Press the yellow Store Button once after storing data
The text field will blink. If the field has no entry, it will display “UNKNOWN” and the first
character will blink.
The Sensitivity control dial can be used to scroll through the alphabet, A-Z, a space character and
then through numbers 0-9. Spin the Sensitivity dial clockwise to move up the alphabet and then to
numbers or counter clockwise to move back through numbers (9-0) and then back down the
alphabet (Z-A).
To enter, click the Sensitivity Control Dial to enter the text character.
The next location to the right will then blink. Continue until through or until all 8 fields are filled.
If an error in recording a letter or number occurs, click the Sensitivity Control Dial and the cursor will
move to the right. Continue clicking the Sensitivity Control Dial and the cursor will “wrap” around to
the right until the desired location is reached. As explained above, spin the Sensitivity Control Dial
until the corrected entry is displayed and “click” the
Sensitivity Control Dial to enter the text character.
When the text is correct, press the yellow Store Button
to save and store the text. The instrument will return
to the Operation Mode.
SETUP MODE
TO ENTER THE SET UP MODE
Make sure the Ultraprobe is off.
Press (click) both the yellow Store button and the Sensitivity dial at the same time. Only after these
two controls have been pressed, then squeeze the trigger.
NOTE:
Hold the Trigger in during any of the Set Up Mode operations.
