15
MENU 04 dB OFFSET
This position is selected to set the dB scale for readings to be taken in dB offset scale. In order
to use the dB offset scale, refer to Menu 03 instructions above.
TO SET THE dB OFFSET SCALE
Make sure the Ultraprobe is off.
Press (click) both the yellow Store button and the Sensitivity dial at the same time, then
squeeze and hold the trigger.
When in the first Menu Selection: “Data Transfer” (Menu 01), the user may move to any of
the other Menu Selections by spinning the Sensitivity Control up or down (clockwise or
counter clockwise).
Spin to “dB Offset Val” value (Menu 04) blinks and click in the Sensitivity Control.
The dB Val (00) will blink.
Spin the Sensitivity Control to the desired dB value level.
Click the Sensitivity Control to set and return to Set Up Mode.
Spin to “Exit to PGM” Exit to Program (Menu 10) blinks. Click to enter Operation Mode.
