UEi DL579 User Manual

8
CAT III
600V 600A
DL579
NCV
Low Z
V
µA
°F °C
TEMP
V
mV
CATIII 600V
CATIV 300V
True RMS
DISCONNECT TEST LEADS
30V MAX
SELECT
INRUSH
RANGE
MAX/MIN
AUTO
AT
µ
CAT III
600V 600A
DL579
NCV
Low Z
V
µA
°F °C
TEMP
V
mV
CATIII 600V
CATIV 300V
True RMS
DISCONNECT TEST LEADS
30V MAX
SELECT
INRUSH
RANGE
MAX/MIN
AUTO
AT
µ
Single
Conductor
Only
AC Amps <600A Jaw
• AC Amps can be measured in any position of the rotary selector dial.
• Center wire in guides for best accuracy.
• Opposing currents cancel each other (use line-splitter when necessary).
• Keep hands below guard when measuring high current levels.
• Do not attempt to measure more than 600A AC.
Features:
AC Amps Measurement - Jaw input
Range Resolution Accuracy Overload Protection
60.00A 0.01A
±2.0% + 8dgts 600V RMS
600.0A 0.1A
45Hz to 400Hz True RMS
Minimum Current for Clamp Measurement: 0.3A
• Rotary selector dial =
any position
• Reading show on
upper display
V
Low Z
