AC Voltage
Overload protection: 250V DC or rms. AC.
Resistance
Maximum Open Circuit Voltage: 3.2V
Overload Protection: 250V DC or rms. AC for all ranges.
Transistor “hFE” Test (0-1000)
UTL33-MAN P
. 4
Range Description
If continuity exists (about less than 1.5k), built-in buzzer
will sound.
Show the approx. forward voltage drop of the diode.
Range Resolution Accuracy
200 Ω 0.1 Ω ±0.8% of reading ±3 digits
2 kΩ 1 Ω ±0.8% of reading ±2 digits
20 kΩ 10 Ω
200 kΩ 100 Ω
600 MΩ 1 kΩ ±1.0% of reading ±2 digits
Range Test Range Test Current Test Voltage
NPN & PNP 0-1000 lb=10 µA Vce=3V
