17
together. (see figure 7)(see figure 8).
figure 7
figure 8
7. 3. 2 DISASSEMBLY
1 To remove the lid of the container, press the top button and
slide the lid towards the front of the container.
If there is a safety lock for the lid, turn the key in an anti-
clockwise direction to release the open button (see figure 9).
figure 9
2 To remove the container, push the lever upwards (see
figure 10) and then remove the container itself (see figure 11).
figure 10
figure 11
3 Remove the mixer by sliding it out of the evaporator
ATTENTION
Before disassembling any component, always unplug
the device from the mains.
