How It Works
Connection and Operation
1. Use HDMI cable to connect the resource device to the splitter.
2. Use HDMI cables to connect the display devices to the splitter.
3. Use the provided power adapter to power the splitter.
4. Press the power button to turn on the splitter.
Indicator Status Introduction
Power Indicator Light: The red light on the panel is the power indicator. When the
product is powered on, the power indicator will be always on.
HDMI Indicator Light: The blue light on the panel is the HDMI input indicator. When the
product is connected, the HDMI input indicator will be always on.
