UGREEN 40203 User Manual

5
Specification
Supports 1 port HDMI input and 8 ports HDMI output
Compliant with HDMI 1.4 version, supports 3D contents, CEC and HDCP 1.4
Supports transmission bandwith of up to 340MHz, supports rate of up to 10.2Gbps
Supports video amplification signal, supports signal timing rectification
Resolution Supported:
4K x 2K@30Hz,
1080p/1080i/720p/576p/480p
Supports
RGB 8/10/12 bpc, YCbCR4:4:4, YCbCr4:2:2,
YCbCr4:2:0 8/10/12 bpc
Supports Audio Format:
DTS-HD/Dolby-True
HD/LPCM7.1/DTS/Dolby-AC3/DSD/HD
(HBR)
Rated Current:
1A
Service Temperature:
(0 to +35°C)
Service Humidity Range:
20 to 80%RH
Power Adapter:
AC Input: 100-240V 50/60Hz
DC Output: 12V/1A
Dimensions:
L301.2 x W89 x H30.2 (mm)
Resolution
4K*2K/30Hz
1920*1080/60Hz
Transmission distance
0.75-24m
0.75-35m
Supporting cable length
Input end
Output end
Input end
Output end
0.75-12m
0.75-12m
0.75-20m
0.75-15m
Note: Length of HDMI cables and corresponding AWG are as follow
Cable length
0.75-3m
5-10m
12-15m
20m
AWG
30AWG
28AWG
26AWG
24AWG
Note: Please make sure all cables and all interfaces are properly connected.
