UI NanoSwitch - Safety Warnings; PoE Voltage and Output Limits; Hardware Installation

WARNING:PoEisalwaysactive.Beforeconnectingadevicetoa
PoEOutport,ensurethatthedevicesupportspassivePoEandthe
suppliedvoltage.
WARNING:DoNOTprovidemorethanatotalof24WPoEoutput
(24V,1A)perportor30Wtotaloutput;otherwisethiswilldamagethe
NanoSwitch.
ConnectaDrainWire(Optional)
IfadrainwireisusedtogroundtheNanoSwitch,attachittotheGroundBonding
PointwiththeSelfTappingScrewandNut.
Attheinstallationsite,securetheotherendofthedrainwiretoagroundedmast,
pole,tower,orgroundingbar.
HardwareInstallation
Followtheappropriatestepsforyourinstallation:
“PoleMounting”
“WallMounting”
PoleMounting
1.IfyouareusingtheSelfTappingScrewforgrounding,removetheMachine
ScrewandNut:
