POLE MOUNT
Pole mount attachments are available for U250 Series Arm units so they can be securely attached
to anesthesia poles. When installing the pole mount be sure you have the right size pole mount
for the pole you are connecting it to. The pole mounts are available in two sizes 1 ¾” and 2”. On
the pole mount there are two allen (Hex) screws, one on either side of the mount. Simply, un-
screw the allen (Hex) screws to open the pole mount. Place the mount around the pole and re-
attach the other half, tighten the screws on the pole mount until tight and secure.
Both Table-Top and Arm units include a standard 12” arm attachment. Additional 6”, 8”, 12” and
16” arm attachments are also available. The Ultima 250 Arm units make it possible to connect to
as many arm attachments as needed to achieve the correct length necessary for any practice
environment. To order additional arm attachments contact the local distributor in your area or call
The UDS Support team directly at (888) 900-8584.
