Ultima 250 Series User Manual

6 | P a g e
www.UltimaDentalSystems.com
Operation
From right to left;
1. The On/Off Toggle Switch – turn the water on/off to the units hand piece lines.
2. The Volume knob – Allows you to increase/decrease and adjust the water to the hand pieces.
3. The bottle Selector Switch – Allows you to change the water source to the hand pieces
between bottles one and two.* You may fill one bottle with cholhexidine solution and one with
distilled water. (IT IS VERY IMPORTANT TO FLUSH THE HAND PIECE TUBING LINES WITH
DISTILLED WATER AFTER USE FOR THIRTY SECONDS TO A MINUTE TO NOT ALLOW
THE CHOLHEXIDINE TO AND FORM PARTICLES INSIDE THE TUBING LINES, WHICH CAN
CAUSE CLOGS AND BLOCKAGE WITHIN THE UNIT).
4. The white cap next to the bottle selector switch is a pre-drilled hole available if you decide to
upgrade to a Piezo Scaler.
You will also find the Ultima 250 units to be extremely user/repair friendly. On the top of the unit
there is an easy to remove lid secured by a silver thumb screw. To gain access to the U250
components simply un-do the silver thumb screw.
(1)
(2)
(3)
)
If the unit has a Piezo electric scaler there
will be a numbered color power dial
Located on the side of the
Ultima 250 Units are the controls
