For the device to operate properly, the socket for the electrical system must have
a voltage between 10.5 V and 14.8 V. Before connecting the device, check
whether the voltage supply provides sufficient power for operation.
z Using the Mini-Compressor
 Place the product on a level and non-flammable surface.
 Do not cover the ventilation openings.
 Do not operate the device in a dusty environment. This is a fire risk and the
device could be damaged.
 A gap of at least 50 cm must be maintained behind the ventilation slots of the
compressor.
 Make sure that the product is switched off.
 Connect the cigarette lighter plug
7
to the 12 V socket of the cigarette lighter.
PLEASE NOTE: You can use the connecting valve
4
directly or together
with the valve adapters
11
,
12
,
13
supplied.
Connecting the compressed air hose without a valve
adapter.
 Undo the connecting valve
4
by pushing the clamp lever
5
upwards
(see Fig. C for position).
 Now push the connecting valve
4
over the valve of the inflatable item
(remove valve cap on the inflatable item first if necessary).
 Then push the clamp lever
5
back down (see Fig. D for position) while
holding the valve firmly.
Connecting the compressed air hose with a valve
adapter
 The valve adapters
11
,
12
and
13
are located on the side of the device.
See Fig. H.
 First fit the required valve adapter
11
,
12
or
13
onto the connecting valve
4
.
 Push the clamp lever
5
downwards to fix the valve adapter in place (Fig. D).
 Connect the valve adapter
11
,
12
or
13
to the connecting valve on the
inflatable item (remove valve cap on the inflatable item first if necessary).
Removing the compressed air hose
 Connecting without the valve adapters
11
,
12
or
13
: Move the clamp lever
5
to an open position (Fig. C) and pull the connecting valve
4
off the inflatable
item.
 Connecting with the valve adapters
11
,
12
or
13
: First undo the valve adapter
from the connecting valve of the inflatable item. Move the clamp lever
5
to
