Ultimate T2-602 - Specifications

T2-602 • T2-604 • T2-5001
T2-SERIES
Specifications
Continuous Power
• 4 ohms (RMS) 65 x 2 65 x 4 320 x 1
• 2 ohms (RMS) 100 x 2 100 x 4 500 x 1
Bridged Power
• 4 ohms (RMS) 190 x 1 190 x 2
Maximum Power
• 4 ohms 130 x 2 130 x 4 640 x 1
• 2 ohms 200 x 2 200 x 4 1000 x 1
THD <0.03% <0.03% <0.08%
Signal to Noise Ratio >90db >90db >80db
Frequency Response 10-25KHz 10-25KHz 10-180Hz
Crossover HPF-FULL-LPF HPF-FULL-LPF LPF
• High Pass (HPF) 50-750Hz 50-750Hz n/a
• Low Pass (LPF) 50-750Hz 50-750Hz 40-180Hz
Speaker Impedance 2 ohms 2 ohms 2 ohms
Damping Factor 220 @ 4 ohm 200 @ 4 ohm 190 @ 4 ohm
Input Sensitivity 200mV – 5V 200mV – 5V 200mV – 5V
Dimensions 7.25” x 9” x 2” 9.25” x 9” x 2” 7.5” x 9” x 2”
Fuse Rating 30A 40A external (see "Fusing")
T2-602 T2-604 T2-5001
