Ultimate T32160 - Page 11

T3 2700 T3 2600 T3 2300, T3 2160
1. Power L.E.D. 2. Speaker level input 3. Line level input
4. input level adjust 5. Bass boost 6. Low pass freq. adjust
7. Crossover select 8. High pass freq. adjust 9. Line level output
10. Protection L.E.D.
1 2 3 4 5 6 7 8 9
10
1. Fuse 2.Power terminals 3 . Speaker terminals
9
