2.4 Operation- Location of Terminals,
Controls and LED indicators
T
3 4600, T3 4320
1. Power L.E.D. 2. Line level output 3. Line input jacks
4. Input level adjust 5. High pass freq. 6. Low pass Freq. adjust
7. Speaker level input 8. Protection L.E.D 9. Crossover select
10. Bass boost 11. Mode Switch
8
1. Fuse 2. Power terminals 3. Speaker terminals
1 2 3 4 5 6 7 6 5 4 3 8
9 10 11 10 9
2 3 3 1
