18 Electrical Connection
Rev A
Electrical Connection
All Ultramax controllers operate on 12-volt alternating current power
supply. This requires use of the GE Water Technologies supplied AC
adapter. A variety of AC adapters are available for different applications.
These AC adapters are available from your supplier. They include:
120 VAC AC Adapters:
Make sure power source matches the rating printed on the AC adapter.
Controller Location
The Ultramax controllers are designed to be mounted on the valve or
attached to a flat surface. Installations that do not provide easy access to
the valve can have the controller mounted for remote operation.
A remote mount connection, PN 1256257, is available for the Ultramax
Series controller.
AC Adapter
Input
Voltage
Application Part Number
Standard wall-mount
AC adapter
120V 60Hz Standard indoor
application
1000811
Outdoor rated AC
adapter
120V 60Hz UL listed for
outdoor
installations
1235448
NOTE: The power source should be constant. Be certain the AC
adapter is not on a switched outlet. Power interruptions longer than 8
hours may cause the controller to lose the time and day settings. When
power is restored, the day and time settings must then be re-entered.
