Ultramax 268 Co-Current Conditione - Control Panel Layout; Ultramax Controller Interface

Control Layout 9
Rev A
Control Layout
Ultramax Controller
LBS
PM
MIN
KG
x100
LCD Display
Manual Regen Button
Down Button
Set Button
Up Button
Lockout Connection
Turbine Input or Dry Contact Signal Input
Main Motor &
Optical Sensor
Connection
AC Adapter
(low voltage)
Input
Refill Sensor Probe Outlet
Secondary Valve
Motor Control
(not used)
