UNAOHM
10 EP2500 (Rev. 0)
MPEG 2 card
Standard
DVB compatible
Video Audio Decompression
MPEG2 Main Level @ Main Profile
Program Viewing
Non encrypted programs
Aspect Ratio
4:3
Sound
Demodulators
VHF/UHF/CATV: AM - FM.
SAT: FM.
Subcarrier Frequency
VHF/UHF/CATV: according to the selected TV-standard.
SAT: from 5 to 9.99 MHz in 10 kHz steps, PLL tuning.
SAT Bandwidth
70 and 300 kHz.
SAT Deemphasis
Flat, J17, 50µs, 75µs.
SAT Noise reduction
Switchable.
Output Power
0.5W max, via loudspeaker.
Auxiliary inputs and outputs
SCART Socket
Complete: input/output video and audio (1V / 75 Ω - 0.3 V / 600 Ω).
Vdc
11 V - 150 mA (automatic protection in case of shortcircuit).
22kHz Tone
0.6 Vpp on 18Ω load, 22kHz ± 1kHz, square wave.
DiSEqC Commands
See DiSEqC section for specifications and features.
Power to LNB
13 or 18 V, 500 mA, automatic protection.
USB Port Standard 1.0. Female “B” type connector for external data exchange
RS 232 Serial Port Female 9 pole "D" type connector for external data exchange.
Power supply
Internal Vdc Power
By means of a sealed rechargeable 12 V / 3.8 Ah Ni-MH battery.
Operational Run
From 1hr 30' to 2hrs depending on the facilities engaged
Battery Charger
By means of an external power supply/charger unit (standard
accessory). Recharge time from 10 to 14 hrs.
External Vdc Power
By means of an external power supply/charger unit (standard
accessory) or any other unit featuring 12 to 18V, 3 A max, 45VA.
Pilot light Warning
LED for “Charge”, OSD for “Battery low” indication.
Mechanical
Dimensions
320x115x335 mm (L x H x D).
Weight
Approximately 5.5 kg with carrying case. and battery fitted.
Finishing
The instrument is contained in an Elite carrying case with accessories
compartment and strap for transport.
