UNI-T UT33B User Manual

l Do not store the Meter in a place of humidity, high temperature, explosive,
inflammable and strong magnetic field.
B. Replacing the Battery (see figure 8)
To avoid false readings, which could lead to
possible electric shock or personal injury,
replace the battery as soon as the battery
indicator “ ”appears.
( figure 8)
Warning
Screw
To replace the battery:
1. Disconnect the connection between the
testing leads and the circuit under test,
and remove the testing leads away from
the input terminals of the Meter.
Maintenance(2)
38
Model UT33B/C/D: OPERATING MANUAL

UNI-T UT33B Specifications

General

Product type	Digital multimeter
AC voltage range	200 - 500 V
DC current range	0.2 - 10 A
DC voltage range	0.2 - 500 V
Basic accuracy (DC current)	±(1%+2)
Basic accuracy (DC voltage)	±(0.5%+2)
Basic accuracy (resistance)	±(0.8%+2)
Dimensions (WxDxH)	73.5 x 35 x 130 mm
Battery voltage	9 V
Battery low indication	Yes

Weight and Dimensions

Weight	156 g
