UNI-T UT58C User Manual

Measurement Operation(4)
Warning
To avoid damages to the Meter or to the devices
under test, disconnect circuit power and discharge
all the high-voltage capacitors before measuring
resistance.
black red
(figure 5)
The resistance ranges are:
Model UT 58A/UT58B:200Ω, 2kΩ, 20kΩ, 2MΩ,20MΩ and
200MΩ.
Model UT 58C:200Ω, 2kΩ, 20kΩ, 2MΩ and 20MΩ.
1. Insert the red test lead into the Hz VΩ (UT58C) or
VΩ (UT58A/UT58B) terminal and the black test
lead into the COM terminal.
2. Set the rotary switch to an appropriate measurement
position in Ω range.
3. Connect the test leads across with the object being
measured.
The measured value shows on the display.
Model UT58A/B/C: OPERATING MANUAL
17
