UT61A, UT61B and UT61C: display effective value of sine wave (mean
value response).
UT61D and UT61E:
display true rms value.
5. Press Hz% to obtain the frequency and duty cycle value.
Input Amplitude: (DC electric level is zero)
Input Amplitude: range 30%
Frequency response:UT61A and B 400Hz
UT61C , UT61D andUT61E 1KHz
Note
l
If the value of current to be measured is unknown, use the maximum measurement
position, and reduce the range step by step until a satisfactory reading is obtained.
l For safety sake, each measurement time for >5A current should be less than
10 seconds and the interval time between 2 measurements should be greater
than 15 minutes.
l When current measurement has been completed, disconnect the connection
between the testing leads and the circuit under test, and remove the testing leads
away from the input terminals of the Meter.
Model UT61A/61B/61C/61D/61E: OPERATING MANUAL
20

UNI-T UT61D Specifications

General

Backlight	Yes
Product type	Digital multimeter
Frequency range	0.01 - 10000 kHz
AC current range	0.6 - 10 A
AC voltage range	0.06 - 750 V
DC voltage range	0.06 - 1000 V
Dimensions (WxDxH)	87 x 180 x 47 mm
Battery voltage	9 V

Weight and Dimensions

Weight	370 g
