UNI-T UT61D User Manual

Warning
T
o avoid damages to the Meter or to the devices under test, disconnect circuit
power and discharge all the high-voltage capacitors before measuring resistance.
To avoid harm to yourself, do not input higher than DC 60V or AC 30V voltages.
To measure resistance, connect the Meter as follows:
1. Insert the red test lead into the terminal and the black test lead into the COM
terminal.
2. Set the rotary switch to resistance measurement ( ) is default or press BLUE
button to select measurement mode.
3. Connect the test leads across with the object being measured. If there is lead on
the resistor or SMT resistor, it is more convenience to use the included multi-
purpose socket to carry out testing.The measured value shows on the display.
Model UT61A/61B/61C/61D/61E: OPERATING MANUAL
22

UNI-T UT61D Specifications

General

Backlight	Yes
Product type	Digital multimeter
Frequency range	0.01 - 10000 kHz
AC current range	0.6 - 10 A
AC voltage range	0.06 - 750 V
DC voltage range	0.06 - 1000 V
Dimensions (WxDxH)	87 x 180 x 47 mm
Battery voltage	9 V

Weight and Dimensions

Weight	370 g
