200.00mV
2.0000V
20.000V
200.00V
1000V
0.01mV
0.0001V
0.001V
0.01V
1V
±(0.8%+25)
±( )1.2%+25
200.00V
1000.0V
0.01V
0.1V
±(2%+30)
200.00mV
2.0000V
20.000V
200.00V
1000V
0.01mV
0.0001V
0.001V
0.01V
1V
±(0.05%+5)
±(0.1%+5)
2000.0µA
200.00mA
20.000A
0.1 Aµ
0.01mA
0.001A
±(1.5%+15)
±(2.5%+35)
200.00 Aµ
2000.0 Aµ
200.00mA
20.000A
0.01 Aµ
0.1 Aµ
0.01mA
0.001A
±(0.5%+4)
±(0.8%+6)
±(2.0%+15)
200.00nS 0.01nS
±(1.2%+50)
200.00Ω
0.01Ω
20.000V
0.001V
20.000nF
200.00nF
2000.0nF
2.0000 Fµ
20.000 Fµ
200.00 Fµ
2.0000mF
20.000mF
200.00mF
0.001nF
0.01nF
0.1nF
0.0001 Fµ
0.001 Fµ
0.01 Fµ
0.1 Fµ
0.001mF
0.01mF
±(4.0%+50)
±(10%)
-40℃～40℃
40℃～400℃
400℃～1000℃
-40℉～104℉
104℉～752℉
752℉～1832℉
0.1℃
0.1℉
±4℃
±(1.0%+5 )℃
±(2.0%+ )5℃
±5℉
±(1.5%+ )5℉
±(2.5%+ )5℉
±(1.0%+25)
X. Maintenance
Warning: Before opening the rear cover or battery cover,
switch off the power supply and remove the test leads.
1. General Maintenance
1) Clean the meter casing with a soft cloth and mild detergent.
Do not use abrasives or solvents!
2) If there is any malfunction, stop using the meter and send it
for maintenance.
3) The maintenance and service must be implemented by
qualified professionals or designated departments.
2. Battery/Fuse Replacement
1) Turn the function dial to the "OFF" position, and remove the test leads from the input terminals.
2) Unscrew and remove the battery cover.
3) Replace with 4×1.5V AAA batteries, observing correct polarity.
Or replace the blown fuse (specifications: F1 Fuse 630mA 250V Φ5x20mm ceramic tube;
F2 Fuse 20A 250V Φ5x20mm ceramic tube)
4) Secure the battery cover and tighten the screw.
Screw
Battery
Fuse
Range
Range
Range
Range
Range
Resolution
Resolution
Resolution
Resolution
Resolution
Accuracy
Accuracy
Accuracy
Accuracy
Accuracy
IX. Specifications
1. General Specifications
1) Max display: 19999
2) Polarity display: Auto
3) Overload display: “OL” or “-OL”
4) Low battery indication: “ ” is displayed.
5) Battery: 4×1.5V AAA
6) Auto power off: If there is no operation of the function dial or any button for 15 minutes, the meter
will automatically power off. This function can be disabled.
7) Dimensions: 189.4mm×89mm×53.8mm
8) Weight: About 370g (including batteries)
9) Operating altitude: 2000m
10) Operating temperature and humidity: 0°C~30°C (≤80%RH), 30°C~40°C (≤75%RH),
40°C~50°C (≤45%RH)
11) Storage temperature and humidity: -20°C~60°C (≤80%RH)
12) Electromagnetic compatibility:
RF=1V/m, overall accuracy = specified accuracy + 5% of range
RF>1V/m, no specified calculation
2. Electrical Specifications
Accuracy: ± (a% of reading + b digits), 1 year calibration period
Ambient temperature: 23°C ± 5°C; ≤80%RH
Temperature coefficient: To ensure measurement accuracy, the operating temperature should be
within 18°C~28°C and the fluctuation range should be within ±1°C. When the temperature is <18°C
or >28°C, add temperature coefficient error: 0.1 x (specified accuracy)/°C.
Overload protection: 1000V
Input impedance: About 10MΩ
Frequency response: 45Hz~400Hz, true RMS display
Accuracy guarantee: 5%~100% of range
AC crest factor: The full-scale value of the AC crest factor can reach 3.0. If the crest factor of a
non-sinusoidal wave is ≤3.0, no additional error will be added. The accuracy of other crest factors
beyond the range are not assessed.
Overload protection: 1000V
LPF reading = measured value × 2 ± (2%+30)
Overload protection: 1000V
Input impedance: About 10MΩ
For mV range, short circuit allows least significant digit ≤5.
Accuracy guarantee: 1%~100% of range
Overload protection: 600V
Overload protection: 600V
Overload protection: 600V
Overload protection: 600V
Measurement result = displayed value – capacitance of open-circuit test leads
For capacitance ≤100nF, it is recommended to use the relative value mode.
Open circuit allows least significant digit ≤20.
1) AC Voltage
Range
Range
Range
Range
Range
Resolution
Resolution
Resolution
Resolution
Resolution
Accuracy
Accuracy
Accuracy
Accuracy
Accuracy
2) LPF AC Voltage
3) DC Voltage
4) AC Current
5) DC Current
Overload protection: 600V
200.00Ω 0.01Ω
±(0.4%+10)
2.0000kΩ
20.000kΩ
200.00kΩ
2.0000MΩ
20.000MΩ
200.0MΩ
0.0001kΩ
0.001kΩ
0.01kΩ
0.0001MΩ
0.001MΩ
0.1MΩ
±(0.4%+5)
±(1.2%+25)
±(5.0%+10)
Range
Resolution
Accuracy
6) Resistance
7) Conductance
8) Continuity
9) Diode
10) Capacitance
11) Temperature
<10Ω: Consecutive beeps
≥50Ω: No beep
Open circuit voltage: About 2.8V
Open circuit voltage: About 2.8V
Measurable PN junction: Forward
voltage drop ≤2V
For silicon PN junction, the normal
value is generally about 0.5V~0.8V.
200.00Hz 60.00MHz～ 0.01Hz 0.01MHz ～
±( )0.1%+3
Range
Resolution
Accuracy
12 Frequency
Overload protection:600V
Frequency response: 45Hz~400Hz, true RMS display
Overload protection:600V
3) Low Battery Detection
When the battery voltage is <4.6V, “ ” is displayed. After the symbol lasts for 20s, the meter
displays "Lo.bt" and automatically shuts down after 60s.
AC crest factor: The full-scale value of the AC crest factor can reach 3.0. If the crest factor of a
non-sinusoidal wave is ≤3.0, no additional error will be added. The accuracy of other crest factors
beyond the range are not assessed.
Accuracy guarantee:5%~100% of range.
Accuracy guarantee:1%~100% of range.
The actual reading shall increase 3 digits if lower than 5% of range.
2) Buzzer Alarm
a.The buzzer beeps once (about 0.25s) at any valid press of buttons or turning of the function dial.
b.The buzzer beeps continuously when the input voltage or current is over range.
Overload protection: 250Vrms
Overload protection: 250Vrms
