UNI-T UTD1062C User Manual

UTD1000 User Manual
Trigger
Trigger sensitivity
Trigger level range
Trigger level accuracy (Typical) applied
on signals of ≥20ns rise or fall time
Pretrigger capability
Holdoff range
Set level to 50% (Typical)
Edge Trigger
Edge type
Pulse Trigger
Trigger mode
Pulse width range
≤1 div
± 5 div from the centre of the screen
± (0.3 div x V/div) (within ± 4 div from the centre of the screen)
Normal mode/scanning mode, pretrigger/delayed trigger. Pretrigger
depth is adjustable.
40ns – 1.5s
Input signal frequency ≥50Hz
Rise, Fall
(Greater than, less than, or equal to) positive pulse; (Greater than,
less than, or equal to) negative pulse.
40ns – 6.4s


UNI-T UTD1062C Specifications

General

Brand	UNI-T
Model	UTD1062C
Category	Test Equipment
Language	English
