7.USB Communication
1. Download and install the PC software (refer to UNI-T Documents Download
Operation Guide).
2. Connect the USB cable to the PC.
3. Users can browse pictures and analyze data through the PC software.
Regarding its usage, retrieve the Software User Manual from the Help
option of the operation interface.
8. Specifications
Sensor
Temperature range
Measurement resolution
Mode
Accuracy
Measuring distance
Response time
Emissivity
IR resolution
Pixel size
Color palette
Wavelength range
Field of view (FOV)
Spatial resolution (IFOV)
Thermal sensitivity (NETD)
Frame rate
Image format
UFPA
-10°C~400°C
0.1°C
Auto gain
±2.0°C or ±2%
25cm
≤500ms (95% of reading)
0.01~0.99 adjustable (default: 0.95)
19,200 pixels (160 × 120)
17μm
Iron red, rainbow, grayscale, red-white, blue-white
8μm~14μm
56° (H) × 42° (V)
11mrad
<50mK
<9Hz
BMP
General parameters
PC software
Data transmission
Product size (L x W x H)
Display type
Display resolution
Battery
Auto power off
Battery life
Charging time
Charging voltage/current
Image storage
Drop test
IP rating
Certification
Storage temperature
Operating temperature
Operating humidity
Altitude
Standard accessories
Yes
Type-C USB interface
236mm x 75.5mm x 86mm
2.8” TFT LCD
320 × 240 pixels
3.7V/5000mAh rechargeable Li-ion battery
5 minutes, 10 minutes, 30 minutes,
off (default: 30 minutes)
≥6 hours
4 hours
5V/2A
Micro SD card
2m
IP65
CE
-20°C~60°C (-4°F~140°F)
0°C~50°C (32°F~122°F)
<90%RH (non-condensing)
≤2000m
User manual, USB cable, 16GB Micro SD card
9.Maintenance
Use a wet cloth or weak soap solution to clean the outer shell of the device.
Do not use abrasives, isopropyl alcohol or solvents to clean the outer shell,
lens or window.
