Unic URW295CR - Hook Assembly Details

18.HOOK
（１８−１）
Nut
Hook
Aplly"LockTight#242"
Apllygrease
Bearing‑Thrustball
90
Apllygrease
Ifthegapofmorethan2mmisconfirmed, checkthehook,thethrustbearings, andthenutsandreplace adeformed(wornout)component.
Entirescrewthread
Springpins
(bothsides)
Enlargedportion wheresealingagent istobeapplied.
