Unic URW295CR - Slewing Mechanism; Slewing Reduction Gear Construction

（19‑1）
19.SLEWING
1Slewingreductiongear
(1)Constructionofslewingreductiongear
Casing
Wormwheel
Breather
Gearshaft
Bearing
housing
Crownnut
Snapring
Teperrollerbearing
Wormshaft
Taperrollerbearing
Ballbearing
Crownnut
Dustseal
Flange
bolt
Nut
