Unic URW295CR - Slewing Reduction Gear Reassembly

(2)Constructiontobetakenwhenreassemblingslewingreductiongear
（19−2）
Assembletheworm
wheelwiththemark"V"
directedupward.
Bearinghousing
Flangebolt
Tightnigtorque:
167±20N‑m
(17±2kgf‑m)
Nut:Apply"LockTight#262"beforetighteningit.
Fillupwithgreasehere.
UseLithiumsoapradicalgrease
(suchasRizonixgreaseNo.1orKyseki)
Note:Tightenthenuttotheextentthat
thegearshaftcanberotatedtoeither
directionwithyourbothhands.
ApplyGreaseto
theinsideof
dustseal.
Reference
Tighteningtorque:20N‑m(2kgf‑m)
Apply"ThreeBond
#1401"toit.
DustSeal
