Unic URW295CR - Column Bolt Tightening; Column Bolt Tightening Torque and Order

1
6
5
8
2
3
9
7 4
２１．１ Tighteningtorqueforboltsfasteningcolumn
andtighteningorder
Column
Turntable
Stopper
InspectionHole
forboltsmountingturntable
BoltsforColumn
ＭＪ６×５０(１２Ｔ)０８Ｈ６５１０６０
Whenassembling,apply"LockTight♯９６２Ｔ"
TightningTorque:２５±２Ｋｇｆ・ｍ
Tightentheboltsinthenumericalorder
asillustedinthefigure.
（２１−１）
